Eco-Loo Toilet basin system

BASIN

• •  Size: 470 x 230 x 147
  • Plug Size: 38mm
  • Wall Mount: 2 x M8 Raw Bolts (Only for individual mounting)
  • 2 x M4 Stainless Slot screws (Only if mounted to Cistern)
  • Facet Mount: All standard facets can be moulded (Hot and Cold)
  • 2 x 25mm hole for mounting facets.
  • Stability Temp: Temperature not to exceed 80°C (Usability 40-60°C)
  • Structured Mat: ABS (Acrylonitrile Butadiene Styrene)
  • Volume: 4.0 L (25mm from Brimful)

CISTERN

Special notice must be taken that the Lifewise Eco-Loo is the only product of it’s kind that can be mounted with six raw bolts/screws to a wall.  A necessary feature,  in vulnerable areas,  to the broad public.

• Size: 350 x 210 x 320
• Inlet Size: 2 x Left and Right (Standard pipe thread 14mm ID)
• Wall Mount: 4 x M6 Raw Bolts(For individual mounting and with Basin)
• Stability Temp: Temp. not to exceed 80°C (Usability 40-60°C)
• Structure Material: ABS (Acrylonitrile Butadiene Styrene)
• Volume: 5.0 – 7.0 L (Adjustable Float)
• Outlet Pipe: 44mm ID
• WC Flushing Cisterns Units: mm (metric)
• Degrees:   Celsius °C

Packaging Dimensions:

• Length …. 480 mm;
• Height …. 360 mm;
• Width …. 240 mm;

Package weight:

• 3,4 kg
